PR-1592 Potting and Molding Compound

A high-hardness potting, and molding compound is PR-1592. It can be used in environments between -70°F (-57°C) and 300°F (149°C). This substance is intended for uses where it must retain its electrical qualities after exposure to extreme humidity and temperatures.

PR-1592 is a two-part, chemically curing polyurethane compound. The product requires an elevated temperature to obtain optimal performance properties for the cure.

Technical Data Sheet for PR-1592 (pdf)
Potting/Molding Application Guide (pdf)

Use

PRC-DeSoto International PRC® polyurethane potting and molding materials are designed for potting electrical connectors and molding electrical cable assemblies. These polyurethane compounds are suitable where high dielectric, abrasion, flexibility, high tensile strength, and excellent hydrolytic stability are required. Note: It is important to read and understand the SDS, process specifications, and technical data sheets before working with these products.

Specifications

MIL-M-24041	SS8850	BOMS8035-2
200AS121	72722-106	917AS719
STW-9245	FMC9369-01	TMS 7505620

Standard Packaging

PR-1590 comes in the following packaged configuration:

There are two Parts – Part A and B of the kit. They are pre-measured and placed in different containers.
160 fl. oz Unit – Part A in a 1/2 gal. can and Part B in a 1 gal. can
40 fl. oz Unit – Part A in a 1 pt. can and Part B in a 1 gt. can
It comes with premeasured mixed material that has been frozen at a very low temperature, which is known as “Premixed and Frozen” (PMF) (also shipped and stored frozen). For high consumption applications, PMF material is the most practical packaging configuration; just thaw and use.
PMF 11-1/4 fl. oz. of sealant in a 12 oz. cartridge
PMF 5-3/4 fl. oz. of sealant in a 6 oz. cartridge
PMF 2-1/4 fl. oz. of sealant in a 2-1/2 oz. cartridge
Other packaging configurations may be available.

Standard PackagingCollapse/Expand

Do you want more information?

From the first phone call up to placing your first order with us, our team goes the extra mile to ensure everything is in place, so you can confidently make your purchase with us and have it delivered accurately and on time.

Specification information provided for reference purposes only. Review specification QPL for verification or consult with engineering services.
